In-Line Lubricator – 1/2″ – TP-2L (Price On Application)

The TP-2L In-Line Lubricator is a durable, high-capacity lubrication unit designed to protect pneumatic tools by delivering a continuous, controlled oil supply directly through the air line. Built with a strong cast-aluminium body and equipped with 1/2″ female pipe threads on both ends, it integrates easily into industrial compressed air systems.

With a 1.4 fl oz reservoir, the TP-2L is suitable for medium to heavy-duty pneumatic equipment, providing extended lubrication cycles and reduced maintenance downtime. Rated for 500 psi maximum working pressure and handling up to 30 cfm at 90 psi, this lubricator delivers reliable performance in construction, fabrication, mining and workshop environments.

Features
• High-capacity in-line lubricator for pneumatic tool protection
• 1/2″ female pipe threads for easy installation
• Cast aluminium body for durability in industrial conditions
• 1.4 fl oz reservoir for longer service intervals
• Automatically lubricates tools for improved reliability and lifespan
• Rated to 500 psi maximum working pressure
• Supports up to 30 cfm at 90 psi airflow

Specifications
• Thread Size: 1/2″ NPT (female both ends)
• Reservoir Capacity: 1.4 fl oz
• Max Working Pressure: 500 psi
• Max Air Flow: 30 cfm @ 90 psi
• Body Material: Cast aluminium

Applications
• Impact wrenches and chipping hammers
• Rock drills, breakers and industrial air tools
• Fabrication and workshop air systems
• Construction and mining maintenance
• Any system requiring continuous lubrication
