In-Line Filter-Lubricator – 1/2″ – TP-2FL (Price On Application)

The TP-2FL In-Line Filter-Lubricator is a robust, dual-function air-line unit designed to protect pneumatic tools by filtering contaminants and delivering consistent lubrication during operation. Built with a durable cast-aluminium body and equipped with 1/2″ female pipe threads on both ends, this unit integrates seamlessly into industrial compressed air systems.

Featuring a 1.4 fl oz reservoir, the TP-2FL provides extended run time between refills while ensuring precise lubrication delivery. With a maximum working pressure of 500 psi and 30 cfm airflow capacity at 90 psi, it is suited for medium to heavy pneumatic tools used across construction, fabrication, mining and industrial maintenance environments.

Features
• Combined in-line filter and lubricator for complete air tool protection
• 1/2″ female pipe threads for quick connection into air systems
• Cast-aluminium housing for durability in industrial conditions
• 1.4 fl oz reservoir for longer lubrication cycles
• Removes contaminants while delivering controlled lubrication
• Rated to 500 psi maximum working pressure
• Supports up to 30 cfm at 90 psi for medium–heavy pneumatic tools

Specifications
• Thread Size: 1/2″ NPT (female both ends)
• Reservoir Capacity: 1.4 fl oz
• Max Working Pressure: 500 psi
• Max Air Flow: 30 cfm @ 90 psi
• Body Material: Cast aluminium

Applications
• Medium to heavy pneumatic tools
• Impact wrenches, rock drills, chipping hammers
• Fabrication and workshop air systems
• Construction, mining and industrial maintenance
• Any system requiring combined filtration and lubrication
